INFRAGAS-305
Heavy-duty Stand-alone Exhaust Gas Analyzer
Available as 4-gas (CO, CO2, HC and O2) and 5-gas (CO, CO2, HC, O2 and NOx) version.
Suitable for testing emissions of Otto-cycle engine-equipped vehicles of any kind, recommended for intense use as in statutory tests.
The INFRAGAS 305 is also equipped with oil filter and air inlet for purging the gas sampling circuitry, for intensive use with 2-stroke engines.
Powered by ASSEMBLAD INFRA-QUEEN infrared gas bench.
Suitable for use as test equipment by means of ASSEMBLAD test line software, and for building a stand-alone combi gas/smoke emission tester by adding an ASSEMBLAD Smoke Meter module.
Approved for statutory tests. Recommended for intensive use.
MAIN FEATURES:
- Capable to run any emission test procedure on 2-and 4- stroke Otto-cycle engine using any kind of fuel (petrol, LPG, CNG)
- Equipped with reinforced dual-stage filters for heavy-duty cycles.
- Equipped with coalescent oil filter and air inlet, with pressure reducer, to clean the instrument automatically.
- Backlit LCD screen, integrated keyboard and printer.
- ASSEMBLAD Service software available for remote monitoring.
- Automatic zeroing function.
- Barometric pressure compensation.
- High-efficiency gas filtering system with WaterstoP® device.
- Fast warm-up time (typical 2 minutes).
- Easy and quick maintenance and calibration.
Technical Data
Measure | Range | Ris. | |||||||||||||||||||||||||||
|
|
|
Power and size | |
Power supply | 12V DC o 220V AC |
Weight | 4,2 Kg |
Dimensions (LxHxP) | 344x160x270mm |
